Tangential fan mixed flow fan are made of three parts: the impeller, the housing and the motor.
Material: Housing-Die cast aluminum
Impeller: galvanized sheet steel
Direction of Rotation: Clockwise or counter clockwise
The Diameter of impeller: 65 mm, 60 mm, 45mm, 30mm
The length of impeller:120mm, 180mm, 240mm, 300mm, 360mm
Speed Range: 1950-2100rpm
Insulation Class: B
Ambient Temperature: -30℃～50℃
Bearings: Self-adjusting Calotte Sleeve Bearing
The Mode of Operation: S1 Continuous operation
A. AC Mixed Flow Fan Crossflow Blower YGF30.300 300x30 is high speed and stable air flow.
B. low noise and high efficiency
C. Large volume flow and long life expectancy
Our AC Mixed Flow Fan Crossflow Blower YGF30.300 300x30 are commonly used in HVAC systems, machinery for heating, ventilating, air conditioning, drying, dehumidifying, etc. Such as electronic air cleaner, hand dryers, electronic oven, gas oven, electronic fireplace, gas fireplace, electric fan good balance condition, etc.
Ningbo Hairong Machinery, founded in 2007, is one of the leading manufacturer of fans and motor covering HVAC area. We specialized in developing and manufacturing refrigeration motors, condensate removal water pumps, external rotor motor powered axial fans, muffin fans, backward curved centrifugal fans, forward curved centrifugal fans, duct fans, blowers and AC Mixed Flow Fan Crossflow Blower YGF30.300 300x30. The products are widely used in the refrigeration, ventilation, fresh air, purification, air conditioning, power electronics, and IT industries.
These pictures can better help you understand AC Mixed Flow Fan Crossflow Blower YGF30.300 300x30
Ningbo Hairong is ISO9001 Quality Management System and ISO14001 Environmental Management System certified, AC Mixed Flow Fan Crossflow Blower YGF30.300 300x30 are CCC, CE approved and most of them are UL approved, as well as RoHS standards complaint.
1)Detailed introduction of AC Mixed Flow Fan Crossflow Blower YGF30.300 300x30
2)Booking container/Coordinating FF
3)Order status reporting & details confirming
1) Pre-Installation services
2) User training
3) Warranty services of AC Mixed Flow Fan Crossflow Blower YGF30.300 300x30
4) Online support
